FEATURES

• Switchable input

• attenuation

• 0dB for guitar-type

• pickups

• -20dB for line level

• signals

• -40dB for speaker

• feeds

• Matches the level and impedance

• with unity gain without

• loading the source

• Can drive signals up long cable

• lengths

• Powered from console

• phantom power or internal

• battery

• Automatic switchover to battery

• if phantom power fails

• Parallel Link Jack output to feed

• amplifiers directly

• Parallel XLR input for

SPECIFICATIONS

• Input Section

• Input Impedance

• 1MOhm (pad at 0dB)

• 47kOhm (pad at -20dB)

• 47kOhm (pad at -40dB)

• Max Input Level

• +9dBu (pad at 0dB)

• +29dBu (pad at -20dB)

• +49dBu (pad at -40dB)

• Connectors

• Two Parallel 1/4" jack connectors and a parallel XLR connector (unbalanced)

• Jack:

• Tip Hot (+ve)

• Sleeve Ground

• XLR:

• Pin 2 Hot (+ve)

• Pin 1 & 3 Ground

• Output Section

• Output: Transformer Balanced

• Max. Output Level: +8dBu into 600 ohms or greater

• Connector: XLR3-32 or equivalent

• System Performance

• Distortion (THD): < 0.005% at 1kHz, 0dBu output

• Noise: < -105dB unweighted, 22hz-22khz, rms*

• Frequency Response: 30Hz to 20kHz, +0dB/-1dB

• General

• Main/Standby battery: 9 volt PP3 type, preferably alkaline.

• Current drain: on phantom - less than 7.5mA, on battery - less than 2mA

• Phantom Power: +20 volts DC to +48 volts DC

• Weight: 650 gms, excluding batteries.

• Overall Dimensions: 59 mm x 124 mm x 143 mm (2.3" x 4.9" x 5.6")
