FEATURES

• 800 W continuous program power capacity
• 76 mm (3 in) copper voice coil
• 40 – 2000 Hz response
• 100 dB sensitivity

SPECIFICATIONS

• 380 mm (15 in) - Nominal Diameter
• 8 ohm - Nominal Impedance
• 6.2 ohm  - Minimum Impedance
• 800 W - Continuous Power Handling
• 400 W - Nominal Power Handling (AES)
• 100 dB  - Sensitivity (1W/1m)
• 40 - 2000 Hz  - Frequency Range
• 76 mm (3 in)  - Voice Coil Diameter
• Copper  - Winding Material
• Glass Fibre  - Former Material
• Ceramic Ring  - Magnet Material
• 16 mm (0.62 in)  - Winding Depth
• 10.5 mm (0.4 in)  - Magnetic Gap Depth
• 1.15 T - Flux Density
