2 x 6" High Performance Passive Speaker

TECHNICAL SPECIFICATIONS

ACOUSTICAL
SPECIFICATIONS

• Freq. Response (-3 dB) : 90 Hz - 16 kHz
• Freq. Range (-10 dB) : 77 Hz - 16 kHz
• Rated Power : 300W AES, 1200W Peak
• H Dispersion : 120° (- 6 dB)
• V Dispersion : 60° (- 6 dB)
• Crossover : 2.1 kHz or Bi-amplified
• Nominal Impedance : 8 Ω
• Maximum SPL :Cont 118 dB, Peak 124 dB
• 2 x Speak-On Sockets, Input & Thru

SYSTEM SPECIFICATIONS

• Recommended Subwoofers : See Systems
Chart for compatible subwoofers
• Recommended System Control : Delta Drive
DSP Control Systems
• Recommended Amplifiers : See Amplifier
load calculation chart

LF TRANSDUCER

• 0606A-6LC- 6" Low Frequency Driver
• 2 Drivers connected in parallel
• 150W AES, 600W Peak
• 1.3" Copper Voice Coil - Ferrite Magnet
• 3L Resistance Coating
• Minimal Power Compression with optimised
air-paths
• Aluminum Demodulation Ring for reduced
distortion

HF TRANSDUCER

• A0775 - 0.75" Exit HF Compression Driver
• 30W AES, 120W Peak
• 1" Voice Coil - Ferrite Magnet
• Alpha Contour Waveguide ensuring
consistent coverage

HOUSING

• Marine Birchply Enclosure
• Granular Scratch Free Polyurea Paint
• Perforated Black, Pressed Steel Grills
• Integrated Handles on Either Side
• Includes a set of round bottom feet for
secure and stable stacking
• Sloped Input Plates
• M10 Flying inserts
• Installation brackets : Alpha Throne (H),
Alpha Throne (V), Alpha Yoke B410

AESTHETIC SPECIFICATIONS

• British Acoustics Signature Umber Brown
Tone
• Blue Decals on Grills for better Aesthetics
• Available in a RAL code of your choice (24
nos, minimum)

OPERATING PARAMETERS

• Operating positions: Can be deployed
horizontally or vertically with the correct
installation brackets or can be used as a
monitor
• Maximum permitted ambient temperature
(Ta max) 55° C (124° F)
• Minimum permitted ambient temperature
(Ta min): -20° C (-4° F)

IP SPECIFICATIONS

• WR Version : IP 54 - Offers greater
resistance against dust & water

OPTIONAL ACCESSORIES

• See system chart for the System Accessories

SIZE

• Product: 457 x 190 x 266 mm (H x W x D)
• Product: 18 x 7.5 x 10.5 inch (H x W x D)
• Packed individually

WEIGHT

• Net : 12.2 Kgs
• Net : 26.9 Lbs

SHIPPING INFORMATION

• Carton Size
760 x 519 x 443 mm (H x W x D)
29.9 x 20.4 x 17.4 inch (H x W x D)
• Gross Weight : 25.3 Kgs / 55.78 Lbs
• Packed : Individually
